Lanthanotus borneensis, Earless Monitor
The Deep Scaly Project - Multiple Institutions
Lanthanotus borneensis
Click for help
skull
Click for more information

Field Museum of Natural History (FMNH 148589)

Image processing: Dr. Jessie Maisano
Publication Date: 14 Feb 2011

Specimens: YPM 6057 | FMNH 148589

ITIS TNS Google MSN

Lanthanotus borneensis is an enigmatic lizard known only from Sarawak, on the island of Borneo, in insular southeast Asia. Lanthanotus is fossorial, nocturnal, and semiaquatic, thus it is rarely observed and little is known of its life habits. Although it is called the earless "monitor", Lanthanotus is actually the sole living representative of Lanthanotidae, a clade closely related to, but different from, monitor lizards (see Varanus gouldii).

Lanthanotus borneensis

Lanthanotus holds a key position in the phylogeny of anguimorph lizards, the majority of which are extinct and thus known only from skeletons. But Lanthanotus itself is very rare in collections, and because specimens are next to impossible to replace (Lanthanotus is completely protected in Sarawak), curators are extremely reluctant to permit destructive preparation. For these reasons, Lanthanotus is a "holy grail" in herpetology, and provides a perfect example of the advantage of high-resolution X-ray CT for studying osteology in precious specimens.

Although Lanthanotus superficially resembles monitor lizards, it is easily distinguished from them by its lack of a gular fold and external ear, its transparent lower eyelid, and its blunt nose and bulbous temporal regions. Osteological features that set Lanthanotus apart include broad palatal shelves, contact of the prefrontal and the postfrontal above the orbits, a vertical suture between the angular and splenial on the medial side of the jaw, and the presence of palatine teeth. Most of these features can be seen in the three-dimensional reconstructions shown on this page, which can be directly compared to those of Varanus gouldii.

This scan revealed two features previously unknown in Lanthanotus. The first is the full extent of osteoderms (bones embedded in the skin) around the skull. In McDowell and Bogert's (1954) landmark study, an X-radiograph of Lanthanotus revealed only the most robust osteoderms on the dorsal aspect of the head. But as shown in the "skeleton only" animations above, Lanthanotus possesses a much more extensive array of osteoderms than could be detected by conventional X-radiography.

The second feature newly revealed by these scans is that Lanthanotus possesses a palpebral bone, a bone in the anterodorsal corner of the orbit (see below). This bone was overlooked previously because it is very reduced and isolated in soft tissue in this taxon -- thus, when specimens were skeletonized, the palpebral was lost. Both the osteoderms and palpebral in Lanthanotus are fully described in a recently published paper (Maisano et al., 2002).

The reduced palpebral bone.

Coronal slice through orbits of YPM 6057 showing position of palpebral deep to osteoderms.

About the Species

This specimen was collected from the Sungei Pesu camp, 4th Division, Bintulu District, Sarawak, Borneo by W. Hosmer in August 1964. It was made available to The University of Texas High-Resolution X-ray CT Facility for scanning by Dr. Jessie Maisano of The University of Texas at Austin and Mr. Alan Resetar of the Field Museum. Funding for scanning and image processing was provided by a National Science Foundation Assembling the Tree of Life grant (EF-0334961), The Deep Scaly Project: Resolving Squamate Phylogeny using Genomic and Morphological Approaches, to Drs. Jacques Gauthier of Yale University, Maureen Kearney of the Field Museum, Jessie Maisano of The University of Texas at Austin, Tod Reeder of San Diego State University, Olivier Rieppel of the Field Museum, Jack Sites of Brigham Young University, and John Wiens of SUNY Stonybrook.

Lanthanotus borneensis
Lateral view of the scanned specimen.

About this Specimen

The specimen was scanned by Matthew Colbert on 4 May 2005 along the coronal axis for a total of 660 slices. Each 1024x1024 pixel slice is 0.046 mm thick, with an interslice spacing of 0.046 mm and a field of reconstruction of 22 mm.

About the
Scan

Literature

Estes, R., K. de Queiroz, and J. Gauthier. 1988. Phylogenetic relationships within Squamata, pp. 119-281. In R. Estes, and G. Pregill (eds.), Phylogenetic Relationships of the Lizard Families. Stanford University Press, Stanford, California.

Gao, K.-q., and M. A. Norell. 1998. Taxonomic revision of Carusia (Reptilia: Squamata) from the Late Cretaceous of the Gobi Desert and phylogenetic relationships of anguimorphan lizards. American Museum Novitates 3230:1-51.

Harrisson, B. 1962. Beobachtungen am lebenden Taubwaran Lanthanotus borneensis. Natur und Mus. 92:38-45. [English translation by P. Gritis, 1989, Bulletin of the Chicago Herpetological Society 24:185-188].

Maisano, J. A., Bell, C. J., Gauthier, J. A., and T. Rowe. 2002. The osteoderms and palpebral in Lanthanotus borneensis (Squamata: Anguimorpha). Journal of Herpetology 36:678-682.

McDowell, S. B., and C. M. Bogert. 1954. The systematic position of Lanthanotus and the affinities of the anguinomorphan lizards. Bulletin of the American Museum of Natural History 105:1-142.

Links

Lanthanotus borneensis page on Wikipedia

Literature
& Links

Three-dimensional volumetric renderings of the skull with the osteoderms, scleral ossicles, hyoid and jaw removed, and of the isolated left mandible. All are less than 2mb.

Skull yaw movie

Skull pitch movie

Skull roll movie

Mandible yaw movie

Mandible pitch movie

Mandible roll movie

Additional
Imagery
